Tascam DR-70D DSLR Camera Audio Recorder


  • Compact, professional-grade audio recorder designed to be used in combination with a DSLR camera
  • Uses an SD/SDHC/SDXC card as recording medium (up to 128 GB)
  • High-quality recording inputs through Tascam original High Definition Discrete Architecture (HDDA) microphone preamps
  • NE5532 operational amplifiers for even higher audio performance (also used on DA-3000)
  • In addition to ordinary stereo recording, simultaneous recording of up to four channels is possible
  • Four channels can be mixed down to a stereo signal

1 in stock

Add to Cart

Tascam DR70D DSLR Camera Audio Recorder
Tascam DR-70D DSLR Camera Audio Recorder £289.99

Free UK shipping on all orders over £50

  • 30 days easy returns
  • Order yours before 2.30pm for same day dispatch
Guaranteed Safe Checkout

About the Tascam DR-70D Recorder

The Tascam DR-70D is a compact and professional-grade audio recorder designed to be used in combination with a DSLR camera. It uses an SD/SDHC/SDXC card as its recording medium, with a capacity of up to 128 GB. The recorder features Tascam’s original High Definition Discrete Architecture (HDDA) microphone preamps, as well as NE5532 operational amplifiers for even higher audio performance. It allows for high-quality recording through its four XLR/TRS combo inputs, which can provide phantom power of +24V/+48V.

Two built-in microphones

The two omnidirectional microphones allow you to easily record natural stereo sound with just this unit. Used together with small shotgun mics, you can even record audio from people speaking in an interview and the ambient sound at the same time (on different tracks), for example, with a compact set up.

4 XLR/TRS combo jacks allow a wide range of setups

Tascam DR-70D with it’s four-channel design enables use of two shotgun mics and the stereo mic to record ambiance and each speaker individually. Since channels 1 and 2 can be set to the stereo input and channels 3 and 4 can be set to the built-in mic, a large variety of microphone setups is possible.

  • MONO/DUAL MONO mode: This is best for recording the audio of a single performer.
  • STEREO/DUAL STEREO mode: This is best for recording with the built-in microphone or a stereo mic.
  • 2MIX/DUAL 2MIX mode: This creates stereo files of the signals of multiple inputs that have been mixed.

Built-in mixer with 4 inputs and 2 outputs

Tascam DR-70D mixer can take a total of 4 channels from among the four XLR inputs that support phantom power, the stereo mini-jack input and the built-in stereo mic. In addition to enable pan and level adjustments, this unit also offers a limiter, a five-setting low-cut filter and a delay that can compensate for distances between mics. Moreover, a mid-side decoding function allows the use of two microphones in mid-side configuration.

High audio quality through HDDA microphone preamps

Tascam DR-70D Mic preamps, which receive and amplify microphone input signals, have a large impact on the quality of the recorded audio material. The DR-70D uses Tascam original HDDA (High Definition Discrete Architecture) microphone preamps that we created through careful selection of parts. For example, we chose the NE5532 for the operational amplifier, which has a strong effect on audio quality. With a mic amp circuit that uses discrete architecture comprised of meticulously-chosen parts, we have achieved an equivalent input noise of −120 dBu.

The A/D converter that converts analogue signals to digital is made by Cirrus Logic and is equivalent to those used in our successful DR series of linear PCM recorders. Recording at resolutions up to 96 kHz/24 bit is supported.

Tascam DR70D Compact and tough design

The designer of the Tascam DR70D focused on making the unit small so that it does not interfere with camera-work when it is attached to a camera support system or stabilizer. The unit has tripod screw threads on the bottom side and a removable camera attachment screw on its top. A hot shoe mount is also included so you can attach the recorder in the way most convenient for you by placing it between a tripod and the camera or on top of the camera with a hot shoe.

  • Stand adapter (¼ inch) on bottom side to attach the unit to a tripod
  • DSLR bracket for easy camera attachment and removal
  • Hot shoe mount (accessible when not using the DSLR bracket)
  • Handles on the front left and right sides protect the screen and can be used to attach a shoulder belt

Camera input and output

The Tascam DR-70D has a camera input jack that can be used to monitor the audio from the DSLR camera. By using this with the DR-70D monitor selection function, you can efficiently monitor the audio from not only the Tascam DR70D but also from the DSLR camera.

The camera output jack is designed to output the mixed audio to the camera so that the same audio can be recorded by the DR-70D and the camera. Since the input level varies by camera maker and there are usually few adjustments related to volume on DSLR cameras, this unit has an output volume dial that can be used to make adjustments.

Slate tone generator for easy alignment with video files

Tascam DR-70D built-in generator can produce slate tones that can be used as references when aligning audio and video. In addition to being able to produce slate tones when recording starts or when it starts and stops, the SLATE button can be used to add slate tones at any desired point.

Automatic insertion: Choose from inserting a slate tone at the beginning of recording or at both the beginning and end of recordingManual insertion: Press the SLATE button to produce a tone.

Additional information


Recording media SD cards (64 MB – 2 GB)
SDHC cards (4–32 GB)
SDXC cards (48–128 GB)
Recording/playback formats WAV: 44.1/48/96kHz, 16/24-bit
BWF: 44.1/48/96kHz, 16/24-bit
Number of channels 4 maximum (stereo x 2)

Analogue audio inputs and outputs
1/L, 2/R, 3/L, 4/R XLR-3-31, 6.3-mm standard TRS jack
(can provide phantom power)
EXT IN 1/2 3.5-mm stereo mini jack
(can provide plug-in power)
IN 3.5-mm stereo mini jack
PHONES 3.5-mm stereo mini jack
OUT/LINE OUT 3.5-mm stereo mini jack

Other inputs and outputs
USB port Micro-B connector
Format USB 2.0 HIGH SPEED mass storage class
REMOTE input 2.5-mm TRS jack

Audio performance
Frequency response (LINE IN or MIC IN to LINE OUT, JEITA) 20 Hz – 20 kHz +0.5/−2 dB (Fs 44.1/48 kHz)
20 Hz – 20 kHz +0.5/−3 dB (Fs 96 kHz)
Distortion (LINE IN or MIC IN to LINE OUT, JEITA) 0.02 % or less (Fs 44.1/48/96kHz)
S/N ratio (LINE IN or MIC IN to LINE OUT, JEITA) 92 dB or more (Fs 44.1/48/96kHz)
Equivalent input noise (EIN) −120 dBu or less

Recording times (4-GB SDHC card, hours: minutes)
WAV/BWF 16 bit/44.1 kHz (stereo) 6:44
WAV/BWF 24 bit/96 kHz (stereo) 2:04

Requirements for connected computers
Supported operating systems Windows XP, Windows Vista, Windows 7, Windows 8 (including 8.1)
Mac OS X 10.2 or newer

Power supply and other specifications
Power 4 AA batteries (alkaline or NiMH)
USB bus power from a computer
AC adapter (TASCAM PS-P515U, sold separately)
External battery pack (TASCAM BP-6AA, sold separately)
Power consumption 5 W (maximum)
Dimensions (W x H x D) 169 mm x 55 mm x 107 mm
(with top adapter attached)
Weight 625g (including batteries)
530 g (excluding batteries)
Operating temperature range 0–40 °C

Approximate battery operation time (continuous operation, hours:minutes)
Alkaline batteries (EVOLTA)
2-ch recording, WAV format, 44.1kHz/16-bit 6:00 (XLR/TRS input selected, phantom power not used)
11:00 (MIC input 3/4 selected)
NiMH rechargeables (eneloop)
2-ch recording, WAV format, 44.1kHz/16-bit 6:15 (XLR/TRS input selected, phantom power not used)
10:30 (MIC input 3/4 selected)
