| Type |
22.3 mm x 14.9 mm CMOS |
| Effective Pixels |
Approx. 24.10 megapixels |
| Total Pixels |
Approx. 25.80 megapixels |
| Aspect Ratio |
3:2 |
| Low-Pass Filter |
Built-in/Fixed |
| Sensor Cleaning |
EOS integrated cleaning system |
| Colour Filter Type |
Primary Colour |
| Image Processor |
| Type |
DIGIC 8 |
| Lens Mount |
EF and EF-S mount |
| Focal length |
Approx. 1.6x the focal length of the lens |
| Image Stabilisation |
Optical Image Stabilizer on compatible lenses |
| Type |
Via optical viewfinder: TTL secondary image-forming phase-difference detection system with AF-dedicated sensor Via LiveView on LCD screen: Dual Pixel CMOS AF System. Phase detection pixels built onto imaging sensor1 |
| AF System / Points |
Via optical viewfinder: 9-point Center AF point is AF cross-type supporting f/5.6. Center AF point is vertical line-sensitive supporting f/2.8. Other AF points are vertical line-sensitive or horizontal line-sensitive AF supporting f/5.6. 2 Via LiveView on LCD screen: Maximum 143 AF points via camera automatic selection 3 Freely position 1 AF point/1 AF Zone max 3,975 points via manual selection 1 |
| AF working range |
Via optical viewfinder: EV -0.5 – 18 (center AF point)4 EV 0.5 – 18 (other AF points) 4 Via LiveView on LCD screen: EV -4 – 18 (f/1.2 at 23 °C & ISO 100) with One-Shot AF |
| AF Modes |
AI Focus, One Shot, AI Servo (AI Servo II algorithm) |
| AF Point Selection |
Via optical viewfinder: Automatic selection: 9 point AF Manual selection: Single point AF |
| Selected AF point display |
Indicated by a transmissive LCD in viewfinder and Quick Control screen |
| AF Lock |
Locked when shutter button is pressed half way in One-Shot AF mode or AF-ON Button is pressed. |
| AF Assist Beam |
Emitted by optional dedicated Speedlite |
| Manual Focus |
Selected on lens |
| Metering modes |
Via optical viewfinder: 63-zone dual-layer metering sensor with Evaluative, partial, spot (centre only) and centre-weighted average available Via LiveView on LCD screen:(1) Evaluative metering (384 zones) (2) Partial metering (approx. 5.5 % of LCD screen) (3)Spot metering (approx. 3.7 % of LCD screen) (4)Center-weighted average metering |
| Metering Range |
Via optical viewfinder: EV 1 – 20 (at 23 °C with 50 mm f/1.4 lens ISO 100) Via LiveView on LCD screen: EV -2 – 20 (at 23 °C, ISO 100, evaluative metering) |
| AE Lock |
Auto: In One-shot AF mode with evaluative metering exposure is locked when focus is achieved. Manual: By AE Lock Button in creative zone modes. |
| Exposure Compensation |
+/-5 EV in 1/3 or 1/2 stop increments (can be combined with AEB). |
| AEB |
3 shots +/-2 EV 1/3 or 1/2 stop increments |
| ISO Sensitivity |
Auto (100-25600), 100-25600 (in whole stop increments) |
| ISO can be expanded to H: 51200 During Movie shooting: Auto (100-12800), 100-12800 (in 1/3-stop or whole stop increments) ISO can be expanded to H: 25600. 4K Movie Max. 6400 |
| Shutter |
| Type |
Electronically-controlled focal-plane shutter |
| Speed |
30-1/4000 sec (1/2 or 1/3 stop increments), Bulb (Total shutter speed range. Available range varies by shooting mode) |
| Type |
Automatic white balance with the imaging sensor |
| Settings |
AWB (Ambience priority, White priority), Daylight, Shade, Cloudy, Tungsten light, White, Fluorescent light, Flash, Custom, Colour Temperature Setting. White balance compensation: 1. Blue/Amber bias +/-9 levels. 2. Magenta/ Green bias +/-9 levels |
| Custom White Balance |
Yes, 1 setting can be registered |
| WB Bracketing |
+/-3 levels in single level increments 3 bracketed images per shutter release. Selectable Blue/Amber bias or Magenta/Green bias. |
| Type |
Pentamirror |
| Coverage (Vertical/Horizontal) |
Approx. 95 % |
| Magnification |
Approx. 0.87x 5 |
| Dioptre Correction |
-3 to +1 m-1 (dioptre) |
| Focusing Screen |
Fixed (Translucent LCD screen for information overlay) |
| Mirror |
Quick-return half mirror (Transmission: reflection ratio of 40:60, no mirror cut-off with EF 600 mm f/4 IS USM or shorter) |
| Viewfinder Information |
AF information: AF points, focus confirmation, AF area selection mode. Exposure information: Shutter speed, aperture value, ISO speed (always displayed), AE lock, exposure level/compensation, spot metering circle, exposure warning, AEB. Flash information: Flash ready, high-speed sync, FE lock, flash exposure compensation. Image information: Card information, maximum burst (1 digit display), Highlight tone priority (D+). Composition information: Grid, Aspect Ratio. Other information: Warning icon. |
| Depth of field preview |
Yes, with Depth of Field preview assigned to a button via Custom Function. |
| Eyepiece shutter |
On strap |
| Type |
Vari-angle touchscreen 7.7 cm (3.0″) 3:2 Clear View II TFT, approx. 1040 K sRGB dots |
| Coverage |
Approx. 100% |
| Viewing Angle (horizontally/vertically) |
Approx. 170° |
| Brightness Adjustment |
Adjustable to one of seven levels |
| Display Options |
(1) Quick Control Screen (2) Camera settings |
| Flash |
| Built-in Flash Coverage |
up to 18 mm focal length (35 mm equivalent: approx. 29mm) |
| Built-in Flash recycle time |
Approx. 3 seconds |
| Modes |
Auto, Manual flash |
| X-sync |
X-Contact is not equipped. 1/200 sec |
| Flash Exposure Compensation |
+/- 2 EV in 1/2 or 1/3 increments |
| Flash Exposure Bracketing |
Yes, with compatible External Flash |
| Flash Exposure Lock |
Yes |
| Second Curtain Synchronisation |
Yes |
| HotShoe / PC terminal |
Yes/ No |
| External Flash Compatibility |
E-TTL II with EX series Speedlites, wireless optical multi-flash support |
| External Flash Control |
via camera menu screen |
| Shooting |
| Modes |
Scene Intelligent Auto (Stills and Movie), Creative Auto, SCN(Portrait, Landscape, Close-up, Sports, Group Photo, Night Portrait, Smooth Skin, Group Photo, Handheld Night Scene, HDR Backlight Control, Food, Kids, Candlelight), Creative filters, Program AE, Shutter priority AE, Aperture priority AE, Manual (Stills and Movie) |
| Picture Styles |
Auto, Standard, Portrait, Landscape, Fine Detail, Neutral, Faithful, Monochrome, User Defined (x3) |
| Colour Space |
sRGB and Adobe RGB |
| Image Processing |
Highlight Tone Priority (3 settings) Auto Lighting Optimizer (4 settings) Long exposure noise reduction High ISO speed noise reduction (4 settings) Multi Shot Noise Reduction Auto Correction of Lens Peripheral illumination, Chromatic aberration correction, Distortion correction, Diffraction correction Digital Lens Optimizer Creative filters (Grainy B/W, Soft focus, Fish-eye effect, Water painting effect, Toy camera effect, Miniature effect, HDR art standard, HDR art vivid, HDR art bold, HDR art embossed) Multi-exposure Resize, Crop (JPEG only) |
| Drive modes |
Single, Continuous L, Continuous H, Self timer (2s+remote, 10s +remote) |
| Continuous Shooting |
Max. Approx. 5 fps. |
| Live View Mode |
| Coverage |
Approx. 100% (horizontally and vertically) |
| Frame Rate |
29.97 fps |
| Focusing |
Manual Focus (Magnify the image 5x or 10x at any point on screen) Autofocus: Dual Pixel CMOS AF (Face detection and Tracking AF, FlexiZone-Multi, FlexiZone-Single) One-shot AF and Servo AF selectable for Stills and Movie |
| Metering |
Real-time evaluative metering with image sensor. Evaluative metering, partial metering, spot metering, center-weighted average metering. |
| Display Options |
Grid overlay (x3), Histogram, |
